Snag Free
| Item NO. | 3D file download | Compare | Net Weight | Gate Feature | Body | Snag Free#ibest*88 | Min. Breaking load#ibest*81 | Meets | Color#ibest*103 | Body#ibest*75 | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| g | Screw gate | Twist Locking | TripleLocking | Captive Pin | EN 362 : 2004 | |||||||
| N-2852-0 | Download | Compare | 108 | ✔ | - | - | - | ✔ | 5000 lbs / 23 kN | ✔ | Anodized | Aluminum alloy, SAE 7075 |
| N-2852 | Download | Compare | 108 | - | ✔ | - | - | ✔ | 5000 lbs / 23 kN | ✔ | Anodized | Aluminum alloy, SAE 7075 |
| N-2852-TR | Download | Compare | 108 | - | - | ✔ | - | ✔ | 5000 lbs / 23 kN | ✔ | Anodized | Aluminum alloy, SAE 7075 |
| N-2852-CP | Download | Compare | 108 | - | ✔ | - | ✔ | ✔ | 5000 lbs / 23 kN | ✔ | Anodized | Aluminum alloy, SAE 7075 |
| N-2852-TRCP | Download | Compare | 108 | - | - | ✔ | ✔ | ✔ | 5000 lbs / 23 kN | ✔ | Anodized | Aluminum alloy, SAE 7075 |
| Item NO. | 3D file download | Compare | Net Weight | Gate Feature | Body | Snag Free#ibest*88 | Min. Breaking load#ibest*81 | Meets | Color#ibest*103 | Body#ibest*75 | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| oz.#ibest*74 | Screw gate#ibest*84 | Twist Locking#ibest*85 | TripleLocking#ibest*86 | Captive Pin#ibest*87 | EN 362 : 2004#ibest*91 | |||||||
| N-2852-0 | Download | Compare | 3.7 | ✔ | - | - | - | ✔ | 5000 lbs / 23 kN | ✔ | Anodized | Aluminum alloy, SAE 7075 |
| N-2852 | Download | Compare | 3.7 | - | ✔ | - | - | ✔ | 5000 lbs / 23 kN | ✔ | Anodized | Aluminum alloy, SAE 7075 |
| N-2852-TR | Download | Compare | 3.7 | - | - | ✔ | - | ✔ | 5000 lbs / 23 kN | ✔ | Anodized | Aluminum alloy, SAE 7075 |
| N-2852-CP | Download | Compare | 3.7 | - | ✔ | - | ✔ | ✔ | 5000 lbs / 23 kN | ✔ | Anodized | Aluminum alloy, SAE 7075 |
| N-2852-TRCP | Download | Compare | 3.7 | - | - | ✔ | ✔ | ✔ | 5000 lbs / 23 kN | ✔ | Anodized | Aluminum alloy, SAE 7075 |
