Gate Srength
| Item NO. | Compare | Net Weight | Gate Feature | Gate Strength | 100% proof loaded | Min. Breaking load | Meets | Color | Body | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| g | Screw gate | Twist Locking | TripleLocking | 3600 Lbs Gate Strength | ANSI Z359.12-2019 | CSA Z259.12-16 | EN 362 : 2004 | ||||||
| N-261-0 | Compare | 305 | ✔ | - | - | - | 3600lbs / 16 kN | 5000 lbs / 23 kN | ✔ | ✔ | ✔ | Zinc Plated | Alloy steel |
| N-261 | Compare | 305 | - | ✔ | - | - | 3600lbs / 16 kN | 5000 lbs / 23 kN | ✔ | ✔ | ✔ | Zinc Plated | Alloy steel |
| N-261G | Compare | 305 | - | ✔ | - | ✔ | 3600lbs / 16 kN | 5000 lbs / 23 kN | ✔ | ✔ | ✔ | Zinc Plated | Alloy steel |
| N-261G-TR | Compare | 305 | - | - | ✔ | ✔ | 3600lbs / 16 kN | 5000 lbs / 23 kN | ✔ | ✔ | ✔ | Zinc Plated | Alloy steel |
| Item NO. | Compare | Net Weight | Gate Feature | Gate Strength | 100% proof loaded | Min. Breaking load | Meets | Color | Body | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| oz. | Screw gate | Twist Locking | TripleLocking | 3600 Lbs Gate Strength | ANSI Z359.12-2019 | CSA Z259.12-16 | EN 362 : 2004 | ||||||
| N-261-0 | Compare | 10.7 | ✔ | - | - | - | 3600lbs / 16 kN | 5000 lbs / 23 kN | ✔ | ✔ | ✔ | Zinc Plated | Alloy steel |
| N-261 | Compare | 10.7 | - | ✔ | - | - | 3600lbs / 16 kN | 5000 lbs / 23 kN | ✔ | ✔ | ✔ | Zinc Plated | Alloy steel |
| N-261G | Compare | 10.7 | - | ✔ | - | ✔ | 3600lbs / 16 kN | 5000 lbs / 23 kN | ✔ | ✔ | ✔ | Zinc Plated | Alloy steel |
| N-261G-TR | Compare | 10.7 | - | - | ✔ | ✔ | 3600lbs / 16 kN | 5000 lbs / 23 kN | ✔ | ✔ | ✔ | Zinc Plated | Alloy steel |
