Gate Srength
| Item NO. | Compare | Net Weight | Gate Feature | Body | Gate Strength | 100% proof loaded#ibest*80 | Min. Breaking load#ibest*81 | Meets | Color#ibest*103 | Body#ibest*75 | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| g | Screw gate | Twist Locking | TripleLocking | Captive Pin | 3600 Lbs Gate Strength | ANSI Z359.12-2019 | CSA Z259.12-16 | EN 362 : 2004 | ||||||
| N-252-0 | Compare | 250 | ✔ | - | - | - | - | 3600lbs / 16 kN | 5000 lbs / 23 kN | ✔ | ✔ | ✔ | Zinc Plated | Alloy steel |
| N-252 | Compare | 250 | - | ✔ | - | - | - | 3600lbs / 16 kN | 5000 lbs / 23 kN | ✔ | ✔ | ✔ | Zinc Plated | Alloy steel |
| N-252G | Compare | 250 | - | ✔ | - | - | ✔ | 3600lbs / 16 kN | 5000 lbs / 23 kN | ✔ | ✔ | ✔ | Zinc Plated | Alloy steel |
| N-252G-TR | Compare | 250 | - | - | ✔ | - | ✔ | 3600lbs / 16 kN | 5000 lbs / 23 kN | ✔ | ✔ | ✔ | Zinc Plated | Alloy steel |
| N-252G-CP | Compare | 250 | - | ✔ | - | ✔ | ✔ | 3600lbs / 16 kN | 5000 lbs / 23 kN | ✔ | ✔ | ✔ | Zinc Plated | Alloy steel |
| N-252G-TRCP | Compare | 250 | - | - | ✔ | ✔ | ✔ | 3600lbs / 16 kN | 5000 lbs / 23 kN | ✔ | ✔ | ✔ | Zinc Plated | Alloy steel |
| Item NO. | Compare | Net Weight | Gate Feature | Body | Gate Strength | 100% proof loaded#ibest*80 | Min. Breaking load#ibest*81 | Meets | Color#ibest*103 | Body#ibest*75 | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| oz.#ibest*74 | Screw gate#ibest*84 | Twist Locking#ibest*85 | TripleLocking#ibest*86 | Captive Pin#ibest*87 | 3600 Lbs Gate Strength#ibest*82 | ANSI Z359.12-2019#ibest*89 | CSA Z259.12-16#ibest*90 | EN 362 : 2004#ibest*91 | ||||||
| N-252-0 | Compare | 8.8 | ✔ | - | - | - | - | 3600lbs / 16 kN | 5000 lbs / 23 kN | ✔ | ✔ | ✔ | Zinc Plated | Alloy steel |
| N-252 | Compare | 8.8 | - | ✔ | - | - | - | 3600lbs / 16 kN | 5000 lbs / 23 kN | ✔ | ✔ | ✔ | Zinc Plated | Alloy steel |
| N-252G | Compare | 8.8 | - | ✔ | - | - | ✔ | 3600lbs / 16 kN | 5000 lbs / 23 kN | ✔ | ✔ | ✔ | Zinc Plated | Alloy steel |
| N-252G-TR | Compare | 8.8 | - | - | ✔ | - | ✔ | 3600lbs / 16 kN | 5000 lbs / 23 kN | ✔ | ✔ | ✔ | Zinc Plated | Alloy steel |
| N-252G-CP | Compare | 8.8 | - | ✔ | - | ✔ | ✔ | 3600lbs / 16 kN | 5000 lbs / 23 kN | ✔ | ✔ | ✔ | Zinc Plated | Alloy steel |
| N-252G-TRCP | Compare | 8.8 | - | - | ✔ | ✔ | ✔ | 3600lbs / 16 kN | 5000 lbs / 23 kN | ✔ | ✔ | ✔ | Zinc Plated | Alloy steel |
